Machining & Cutting Center for Sectional Doors
SCM-500
It is designed for machining & cutting of sectional door panels as a line.
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
- It is designed for machining & cutting of sectional door panels as a line.
- 3+1 axes servo motor controlled with motion control technology.
- Workable part sizes; width:1000 mm (in Y axis), Length:13500 mm. (in X axis), Height: 100 mm (in Z axis, thickness of the doors)
- Processes in machining unit for sectional door panels;
- Hinge holes
- Window channels
- Processes in cutting unit;
- Cutting sectional door panels according to length (in x axis, sizing width of the sectional door panels)
- Dividing sectioanal door panels (in y axis, sizing height of sectional door panels)
- Cutting lenght sensitivity is +/- 0,5 mm.
- Cutting angles: 90⁰ and 180⁰
- Pc controlled with Windows operating system.
- Easy and fast data transfer because of Pc (by usb memory, cable, cd, wireless, Ethernet, mail etc.)
- Remote control service technology.
- Unlimited data memory.
- Thanks to 15.6’’ lcd control screen for being user-friendly
- Barcode system for mass production.
-
